First Data FD150 Technical Characteristics

Please refer to the Hardware Matrix for the First Data FD150 to verify additional compatibility by partner.

Compact design
Cortex A5 500MHz processor
Supports ATM, debit, EBT, and check payments (configuration dependent)
Fast thermal printer (up to 18 lines per second)
IP connectivity with optional dial backup; optional Wi-Fi (configuration dependent)
Durable keys
Touchscreen-capable 320×240 color display
Merchant-friendly one-touch keys for daily functions
Three-track magnetic stripe reader
Contactless (NFC) support
128MB RAM (standard)
Three USB ports
Address Verification Service (AVS)
Batch history
Simplified installation and support
2.3" wide thermal roll printer
EMV chip transaction support
PCI-PED Version 5.x approved

Category	Details
Processor	Cortex A5 500MHz
Display	320×240 color display; touchscreen capable
Memory	128MB RAM (standard)
Card Acceptance	Chip (EMV): Supported Magnetic Stripe: Three-track reader Contactless (NFC): Supported (configuration dependent)
Connectivity	IP: Supported Dial Backup: Optional (analog line required) Wi-Fi: Optional (configuration dependent)
Ports	3 × USB ports
Printer	Thermal roll printer, 2.3" wide; up to 18 lines per second
Payments Supported	Debit (PIN/signature), major credit cards, contactless, gift cards; optional check acceptance
Security & Compliance	PCI-PED Version 5.x; EMV chip capable
Operational Features	One-touch daily function keys, batch history, AVS support

Note: Feature availability may vary by processor, program, and terminal configuration.

Note: First Data FD150 terminals are available for special order. Please consult with Sales Support for additional details.
