PAX A35 Integrated Smart PINpad Technical Characteristics

Please refer to the Hardware Matrix for the PAX A35 Series to verify additional compatibility by partner.

Category	Details
Operating System	PAXBiz® powered by Android™ 10.0
Processor	Application CPU: ARM Cortex A53 Security CPU: ARM
Memory	Flash / DDR: 8GB Flash + 1GB DDR Expansion: Optional 128GB microSD
Card Readers	Chip & PIN \| NFC Contactless \| Magnetic Stripe
Cameras	Front: 0.3MP fixed-focus Optional Front: 0.5MP fixed-focus
Display	4" WVGA (480 × 800) pixels, capacitive touch screen
Communications	Wired: RS232 \| Ethernet \| USB 2.0 Wireless: Wi-Fi (2.4GHz & 5GHz) + Optional Bluetooth® (4.2/5.0)
Adapter	Input: 100–240VAC, 50Hz/60Hz \| Output: 5.0V DC, 1.0A
SIM / SAM	2 × PSAM
Keys / Buttons	13 keys: 0–9, Enter, Clear, Cancel; Back-lighting optional
Audio	1 × Speaker \| 1 × Audio Jack
Ports	Multi-functional port \| Kensington lock \| MicroSD (optional)
Physical	163.6 × 76.9 × 30.1 mm \| 260 g
Environmental	Operating Temperature: 0°C to 50°C (32°F to 122°F) Storage Temperature: −20°C to 70°C (−4°F to 158°F) Relative Humidity: 5% – 93% (non-condensing)
Accessory Options	Communication cables \| Gigabit Ethernet \| Power over Ethernet (via PoE splitter) \| Power over USB \| Pole stand
Certifications	PCI PTS 6.x SRED \| EMV L1 & L2 \| EMV Contactless L1 \| Visa payWave \| MasterCard Contactless (UICS) \| Amex ExpressPay \| Discover D-PAS \| JCB / J-Speedy \| Interac Flash \| MasterCard TQM \| UL \| FCC \| IC \| CE \| RoHS
