PAX A77 Smart Mobile POS Technical Characteristics

Please refer to the Hardware Matrix for the PAX Android A77 Smart Mobile POS Series to verify additional compatibility by partner.

Category	Details
Operating System	PAXBiz® powered by Android™ 8.1
Processor	Application CPU: Cortex®-A53 Security CPU: ARM
Memory	Flash / DDR: 8GB Flash + 1GB DDR (optional 16GB + 2GB) Expansion: microSD card slot up to 128GB
Card Readers	Chip & PIN \| NFC Contactless \| Magnetic Stripe
Cameras	Front: 0.3MP fixed-focus Rear (optional): 5.0MP fixed-focus with 1D/2D barcode scanner (higher-quality option available)
Display	5.5" IPS, 720 × 1440 pixels; multi-touch capacitive HD touch screen
Configurations	4G + Wi-Fi 2.4 GHz + Bluetooth® Optional: 4G + Wi-Fi 5 GHz + Bluetooth® 5.0
Battery	High-capacity 3.8V Li-ion (≈5000 mAh class)
SIM / SAM	1 × Micro SIM + 2 × SAM (other configurations available, e.g., 2 × Micro SIM + 1 × SAM)
Positioning	GPS / GLONASS
Keys / Buttons	4 keys: Power (ON/OFF) \| Vol + \| Vol − \| Quick Scan button
Audio	1 × Speaker \| 2 × Microphones \| 1 × Audio Jack \| 1 × Receiver
Ports	USB Type-C multi-functional port \| POGO pins \| Kensington lock \| microSD (optional)
Physical	164 × 78 × 17.8 mm \| ~240 g (varies by version)
Environmental	Operating: 0°C to 50°C (32°F to 122°F) Storage: −20°C to 70°C (−4°F to 158°F) Humidity: 5% – 93% non-condensing
Accessories	Charging base \| Leather case \| Hand strap
Certifications	PCI PTS 6.x SRED \| EMV L1/L2 \| EMV Contactless L1 \| Visa payWave \| MasterCard Contactless \| American ExpressPay \| Discover D-PAS \| Interac Flash \| MasterCard TQM \| CE \| FCC \| IC \| RoHS
