PAX A920 Pro Smart Mobile Technical Characteristics

Please refer to the Hardware Matrix for the PAX Android A920 Pro Smart Mobile series to verify additional compatibility by partner.

Category	Details
Operating System	PAXBiz® powered by Android™ 8.1
Processor	ARM Cortex-A53 Quad-Core, 1.4GHz + Secure Processor
Memory	Standard: 8GB Flash + 1GB DDR RAM Optional: 16GB Flash + 2GB DDR RAM (up to 32GB Flash + 3GB DDR RAM) Expansion: microSD card slot (supports up to 128GB)
Card Readers	Chip & PIN \| NFC Contactless \| Magnetic Stripe
Cameras	8MP rear AF camera with flashlight
Display	6" IPS HD+ multi-touch capacitive screen \| 720 × 1440 pixels
Comms Configurations	4G + Dual-Band Wi-Fi (2.4GHz/5GHz) + Bluetooth® 5.0
Battery	5150mAh \| 3.8V Li-ion rechargeable battery
Printer	58mm thermal printer \| 40mm paper roll diameter \| 80mm/sec print speed
SIM / SAM	1 × Micro SIM + 2 × SAM
Positioning	AGPS \| GPS \| GLONASS \| BEIDOU
Keys / Buttons	Power \| Volume+ \| Volume− \| Quick Scan Button
Audio	1 × Speaker \| 1 × Microphone
Ports	1 × Type-C (OTG) \| 6-pin POGO interface
Adapter	Input: 100–240V AC, 50/60Hz \| Output: 5.0V DC, 2.0A
Physical	~165 × 79 × 63 mm \| ~445 g (including battery)
Accessories	USB cable \| Power adapter \| Charging base \| Shoulder strap \| Optional: LAN base \| Bluetooth handset
Environmental	Operating: 0°C – 50°C (32°F – 122°F) Storage: −20°C – 70°C (−4°F – 158°F) Humidity: 5% – 93% non-condensing
Certifications	PCI PTS 6.x SRED \| EMV L1/L2 \| EMV Contactless L1 \| Visa payWave \| MasterCard Contactless \| American ExpressPay \| Discover D-PAS \| UnionPay QuickPass \| JCB J/Speedy \| Interac Flash \| MasterCard TQM \| CE \| FCC \| IC \| RoHS
