PAX Aries 8 Smart Tablet Technical Characteristics

Please refer to the Hardware Matrix for the PAX Android Aries 8 Smart Tablet series to verify additional compatibility by partner.

Category	Details
Operating System	PAXBiz® powered by Android™ 7.1
Processor	Cortex®-A9 + ARM secure processor
Memory	System: 8GB eMMC + 512MB DDR Expansion: microSD card slot (up to 128GB)
Card Readers	Hybrid Chip & PIN \| Magnetic Stripe \| NFC Contactless
Cameras	Optional front-facing camera / scanner
Display	4.0" IPS WVGA (480 × 800) multi-touch capacitive screen
Comms Configurations	4G + Wi-Fi 2.4 GHz + Bluetooth® 4.2 + Ethernet
Battery	4800mAh \| 3.8V Li-ion
Printer	None
SIM / SAM	1 × Micro SIM \| 1 × Nano SIM \| 1 × SAM (other configurations available)
Positioning	GPS
Keys / Buttons	Power (ON/OFF) \| Volume+ \| Volume− \| P1 \| Cancel \| Clear \| Enter
Audio	1 × Speaker \| 1 × Microphone
Ports	1 × Type-C (OTG) \| 1 × Audio Jack \| 6-pin POGO interface
Adapter	Input: 100–240V AC, 50/60Hz \| Output: 5.0V DC, 2.0A
Physical	~162 × 72 × 19 mm \| ~270 g (including battery)
Environmental	Operating: 0°C – 50°C (32°F – 122°F) Storage: −20°C – 70°C (−4°F – 158°F) Humidity: 5% – 93% non-condensing
Accessories	Charging base \| Leather case \| Hand strap (options vary by region)
Fingerprint Reader	Optional
Certifications	PCI PTS 5.x SRED \| EMV L1/L2 \| EMV Contactless L1 \| Visa payWave \| MasterCard Contactless \| American ExpressPay \| Discover D-PAS \| JCB J/Speedy \| Interac Flash \| CE \| FCC \| IC \| RoHS
